Start on your own server

Self-host is one file with SQLite built in. Run it, make an admin key, and tell it which domains links may send people to.

Flags go before the command. Want Postgres instead? Pass a postgres:// address to -db and run migrate first. The full self-host guide covers servers, backups and proxies.

# 1. Start it (creates the database)
./affiliate-engine -listen :8080 -db sqlite:affiliate-engine.db

# 2. Make an admin key. It's shown once
./affiliate-engine -db sqlite:affiliate-engine.db \
  keygen -scope admin -name ops

# 3. Where links may go, and your address
AE_ALLOWED_DEST="yoursite.com"
AE_PUBLIC_URL="https://track.yoursite.com"

# Health check
curl https://track.yoursite.com/healthz

Connect your site

Tracking links record the click. The script keeps the token on your domain until checkout.

Tracking links

Every affiliate link goes through /r/ and lands on an allowed page with a signed token.

https://yourbrand.affiliatetracking.co/r/jane
  ?dest=https://yoursite.com/pricing
  &subid=newsletter&utm_source=youtube

subid, utm_source and placement get their own columns in the affiliate's stats.

The script, t.js

It saves the token in a first-party cookie called at_token, then removes it from the address bar. The cookie lasts your attribution window: 30 days by default, 1 to 365.

// In the browser
AffiliateTracking.token()            // the raw token
AffiliateTracking.clientReferenceId() // at1_... for Stripe

Moving from another tool? data-param="via" (or fpr, or ref) keeps old links working.

Connect billing

Each billing tool sends events to its own address. Each has a full setup guide.

On cloud, put these after your workspace address and paste secrets into Settings. On self-host, set the environment variables.
Billing tool	Webhook address	Self-host settings	Setup guide
Stripe	`/webhooks/stripe`	`AE_STRIPE_SECRET` (whsec_)	Stripe guide
Paddle	`/webhooks/paddle`	`AE_PADDLE_SECRET`	Paddle guide
Lemon Squeezy	`/webhooks/lemonsqueezy`	`AE_LEMONSQUEEZY_SECRET`	Lemon Squeezy guide
Polar	`/webhooks/polar`	`AE_POLAR_SECRET`	Webhook events order.paid and order.refunded
Chargebee	`/webhooks/chargebee`	`AE_CHARGEBEE_USERNAME`, `AE_CHARGEBEE_PASSWORD`	Chargebee guide
Recurly	`/webhooks/recurly`	`AE_RECURLY_USERNAME`, `AE_RECURLY_PASSWORD`, `AE_RECURLY_API_KEY`	Recurly guide

REST API

67 routes: 46 for admins, 11 for affiliates and 10 public. Everything is JSON under /api/v1.

Keys and limits

Send a key as a bearer token. Admin keys see everything. Affiliate keys see one affiliate. Keys start ae_, and we only store a hash.

curl https://yourbrand.affiliatetracking.co/api/v1/admin/dashboard \
  -H "Authorization: Bearer ae_..."

Limits: 600 requests a minute per key. After 30 failed tries a minute from one IP, it answers 429.

Affiliate and public routes

GET /affiliate/earnings Totals, 30-day stats and the ledger proof
GET /affiliate/ledger Journals, page by page
GET /affiliate/payouts Their payouts: amount, method, paid or on its way
GET, PUT /affiliate/payout-details Where they want to be paid (PayPal, Wise or bank; stored encrypted)
GET /affiliate/resources Banners, logos, text and links from the program
GET /affiliate/stats/drill By subid, utm_source or placement
GET /affiliate/uniques Daily unique visitors
GET /affiliate/profile Level and badges
POST /portal/apply Apply to a program
POST /portal/login, /portal/logout Portal sessions
POST /portal/login-link Email an affiliate a one-time sign-in link
GET, POST /portal/unsubscribe Stop program emails: news, tips and recaps (link in each email)
GET /leaderboard, /portal/brand, /portal/logo Public program info and logo
GET /portal/resources/{id}/image A banner or logo from the program, for partners' sites

Admin routes, under /api/v1/admin

Program

GET dashboard
GET, POST campaigns
GET, POST rules
GET, POST, DELETE tiers
GET, POST, DELETE resources
POST resources/image
GET, PUT branding
PUT, DELETE branding/logo
PATCH campaigns/{id}
GET, PUT settings

Affiliates

GET affiliates
PATCH affiliates/{id}
PUT affiliates/{id}/rate
GET, POST, DELETE codes
GET portal/applications
POST portal/review

Money

GET fraud/queue
POST fraud/resolve
POST payouts/run
POST payouts/approve
GET, POST taxdocs
GET payouts
GET payouts/export/{paypal,wise}.csv

More

POST usage
POST mlm/run
POST mlm/place
POST import
GET import/batches
POST import/undo
GET setup-check
POST setup-check/site
POST setup-check/start

Command line

Self-host only. The pattern is affiliate-engine [-db address] [-listen addr] command. With no command, it serves.

Command	What it does
`keygen -scope admin -name ops`	Makes an API key. Use `-scope affiliate -affiliate 42` for one affiliate.
`doctor`	Runs 6 integrity checks. Exits 1 if the money doesn't add up. SQLite.
`backup [out.db]`	Copies the database while it runs. SQLite.
`restore -from backup.db`	Checks the backup, then swaps it in. SQLite.
`migrate`	Sets up or updates the database. Run it first on Postgres.
`import -from rewardful -csv f.csv --dry-run`	Imports affiliates, codes and coupons. Also firstpromoter, tapfiliate or tolt. `-list` shows batches and `-undo ID` undoes one. The admin screen does the same.
`compare`	Puts your old tool's latest export next to this install's data for a day or range: clicks, new customers and commission, with the difference.
`screen-backfill -dry-run`	Runs the fraud rules over sales that releases before v0.5.0 never screened. Drop `-dry-run` to hold what it finds. Safe while the server runs.
`test-conversion -affiliate 42`	Pushes a test sale through the real engine, fraud checks included.
`gdpr-export`, `gdpr-erase`	Exports or erases one affiliate's data. The books still balance.
`export-parquet -out dir`	Writes your data as Parquet files for analysis.
`bench`, `version`, `help`	Click benchmark, version and help.

Settings

Self-host reads these environment variables. On cloud, we set the core ones for you.

Variable	What it sets	Default
Core
`AE_ALLOWED_DEST`	Domains links may send people to, separated by ;	example.com
`AE_PUBLIC_URL`	Your public address. https also makes cookies Secure	From the request
`AE_MAIL_PROVIDER`	postmark or resend turns on partner emails: sign-in links and payout notes. Needs AE_PUBLIC_URL	Off
`AE_MAIL_KEY`	Your Postmark server token or Resend API key	None
`AE_MAIL_FROM`	An address your provider has verified. Emails show your program name in front of it	None
`AE_MAIL_REPLY_TO`	Where partner replies go	The From address
`AE_OWNER_EMAIL`	Where your "something needs you" email goes (change it in Settings)	Your reply-to address
`AE_TOKEN_SECRET`	Signs tokens. At least 32 bytes	Made and saved on first start
`AE_SECRET_FILE`	Where it keeps that generated secret	Next to the database
`AE_TRUSTED_PROXIES`	Proxies allowed to pass the visitor's IP and country	None
`AE_COOKIE_SECURE`	1 sets Secure on every cookie	Off
`AE_REDIRECT_RATE_PER_MIN`	Link clicks per IP per minute. -1 turns it off	120
`AE_MIGRATE_DATABASE_URL`	Owner address for migrations, for a two-role Postgres setup	Unset
Stripe sales filter
`AE_STRIPE_PRODUCTS`	Product, price or Payment Link IDs that earn commission	Every sale counts
`AE_STRIPE_API_KEY`	Restricted key with Checkout Sessions read, for one-time checkouts	Unset
Fraud and privacy
`AE_FRAUD_DRYRUN`	1 scores sales without holding them	Off
`AE_IP_MODE`	trunc24 trims each IP to its /24 (IPv4) or /48 (IPv6) before hashing, so the per-IP click speed rule counts by network	off
`AE_CLICK_RETENTION_DAYS`	Days before it deletes raw clicks. 0 keeps them	90
Other
`AE_DEMO`	1 runs a public read-only demo that resets daily	Off

MCP and postbacks

Both come with self-host and with cloud.

MCP server

Ask Claude, Cursor or any MCP client about your program. It reads, and never changes anything. Point your client at /mcp with an admin key as the bearer token.

Tools: earnings_summary, dashboard, fraud_queue, program_digest, usage_meter.

Postbacks

Send each sale to an affiliate's own tracker. Set a postback URL on the affiliate with PATCH /admin/affiliates/{id} (the same call pauses or resumes a partner with {"status":"frozen"} or "active"). Failed calls retry up to 5 times.

https://tracker.example/pb?order={order_id}
  &amount={commission_cents}&cur={currency}

# Every call carries a signature
X-AE-Signature: t=<unix>,v1=<HMAC-SHA256>
